Product Description

Features

• Turn-key design

• Fully pneumatic

• Vertical Design

• Non clogging

• Translucent reservoir

• Isolated trigger assembly

• Full port ball valve

• Versatile for many applications

Benefits

• Easy to install

• No electricity required

• Takes up less floor space

• No strainers to clean

• Easy-to-see condensate level “Quick check”

• Keeps debris out of trigger mechanism

• Provides rapid discharge and reduces clogging

• Can be used for aftercoolers, receivers, dryers, or filters

How It Works

Condensate enters the drain through one of two inlet connections. A Stainless-Steel float is tethered to a lever arm. As condensate is collected and fills the Translucent reservoir, the float rises. When the condensate reaches a designated level, the float lifts the trigger assembly and a drain cycle is initiated. The trigger assembly opens and directs control air to the valve actuator, which in turn opens the ball valve.

Condensate will then exit the unit. As the condensate level drops, the trigger assembly closes and the valve actuator closes the ball valve. The drain is returned to a standby condition.
