Product Description
• Best Warranty for Belt-Drive Compressors!
6 Year Air End Warranty, 5 Year Warranty on the Motor, Coolers, and Reservoir
• 48 hour “Uptime” assurance plan
• Compressor featuring High efficiency, heavy duty air end with eta-v profile rotors
• Encapsulated design with major components such as intake, compression, and separation systems integrated for compact design, leak free operation, and minimal pressure drop
• Premium Efficiency TEFC motor with Class F Insulation
• Air end and motor connected via simple belt drive arrangement
• High efficiency air filter with pre-filtration mat. Intake air taken from outside package
• Direct “across the line” starter mounted in control panel
• Superb quality inlet valve assembly with load/unload control and timed shutdown
• 3 stage air/oil separation system with verified low oil carryover of less than 2 ppm
• Oversized air-cooled oil cooler and after cooler assembly designed for high ambient applications. Coolers mounted in separate compartment providing excellent access for cleaning. Pre-filtration mat is included to ensure coolers remain clean
• High capacity “spin on” 10-micron oil filter element
• Microprocessor controller with pressure transducer and temperature sensor
• UL/cUL control panel with premium electrical components and phase monitor
• Heavy duty full enclosure complete with powder coated panels and (3) service doors providing easy access to maintenance items and very low sound
• Full complement of safety features with shut down and fault codes for ease of troubleshooting
• Factory fill with “Airlube UT” premium PAO/POE synthetic lubricant designed for 8,000-hour life
