Product Description
Standard Features
• 38oF pressure dew point
• High quality, fully hermetic refrigerant compressor
• Air-cooled refrigeration condenser
• Environmentally friendly refrigerant
• High pressure moisture separator
• Protection against high pressure exchanger leak
• 680 psig maximum operating pressure
• Stainless steel CFX® heat exchangers
• Digital Performance Controller (parameters vary per PETX model)
• Refrigerant suction pressure gauge (9PETX –16PETX)
• High pressure solenoid condensate drain
• ASME and CRN pressure vessel rating
• Fully enclosed, powder coated cabinet
Optional Features
• Water-cooled refrigeration condenser (9PETX–19PETX)
• Weatherproof protection against rain and splashing water
• NEMA 4 electrics (9PETX-19PETX)
• Complete 304L stainless steel air circuit
• Prefilter: 1 micron ZTF
• Afterfilter: .01 micron ZTF
Product Videos
Custom Field
Capacity 384 SCFM
In/Out Air Connect Size 2” MPT
Connection 1/4” FPT
Working Pressure 680 PSI
Refrigerant Compressor 1.0 HP
Operating 1.59 kW
Voltages 208V/230V-3ph-60hz, 220V-3ph-50hz, 460V-3ph-60hz, 380V-3ph-50hz
Length 33 in
Width 28 in
Height 43 in
Weight 335 lbs
