Product Description
The Mikropor MK-US-25 is a 25 scfm cycling refrigerated compressed air dryer from the Mikropor MK-US Series. It removes moisture from compressed air leaving the compressor, which can otherwise cause system errors, reduce productivity and affect the quality of finished products. The dryer uses R134a refrigerant, with R513a available as an option.
Features
- Low pressure drop to reduce compressor power consumption
- Quick start and reaction time
- Components selected for low energy consumption
- R134a refrigerant; R513a refrigerant optional
- Pressure switches control the condenser fan motor to save energy and keep the system at desired operating conditions
Applications
Food production, dairies, breweries, conveying air, chemical plants, clean-room technology, pharmaceuticals, weaving machines, photo labs, paint spraying, powder coating, packaging, control and instrument air, sand and shot blasting, microchip production, optics, process air and general air work.
Details
- Brand: Mikropor
- Part number: MK-US-25
- Series: MK-US Series
- Capacity: 25 scfm
- Type: Cycling refrigerated dryer
- Condition: New
- Weight: 71 lbs
- Ships from: San Juan, Texas
Sold by ProParts, Inc. Technical support is available by phone from ProParts compressor technicians.
Product Videos
Custom Field
Capacity 25 scfm
Voltage 115V/1Ph/60Hz
Connection Size 1/2in NPT
Filter Quality and Type 1*GKON55X+1*GKON55Y
Replacement Filter Element Kit MKON55 KIT
Pressure Kit 2.5 psi
Control Type DigiPro
Length 14.6 in
Width 14.5 in
Height 27.8 in
Weight 71 lbs
Product Line Mikropor MK-US Cycling Refrigerated Air Dryer
Capacity (FAD) 25 cfm
Air Connection 1/2" NPT
Replacement Filter Kit MKON55 KIT
Pressure Drop 2.5 psig
Controller DigiPro
Dimensions (L x W x H) 14.6 x 14.5 x 27.8 in
Type Digital Cycling Refrigerated Dryer
Max Working Pressure 232 psig
Max Inlet Temperature 140°F
Refrigerant R-513a
Cooling Air-Cooled
