Product Description
The Zeks 100NCJ is a 100 SCFM NC Series non-cycling refrigerated air dryer that delivers clean, dry compressed air to protect tools, equipment and processes from moisture-related damage. It uses a constant pressure valve and a variable-speed fan for consistent performance and controlled energy use. The NC Series covers 12 models from 7 to 250 SCFM, suited to systems with 2.5 to 40 compressor horsepower.
Details
- Brand: Zeks
- Part number: 100NCJ
- Capacity: 100 SCFM
- Type: NC Series non-cycling refrigerated air dryer
- Refrigerant: R513A, low Global Warming Potential (GWP)
- Certifications: Safety certified to UL 60335-1, 60335-2-40 and CSA standards
- Drain: Internally mounted timed solenoid condensate drain
- Enclosure: Powder coated, industrial grade finish
- Filtration: Zeks Grade G and H pre and post filters, shipped loose (75 to 250 SCFM models)
- Fan speed control: Variable speed fan adjusts to low load conditions to maintain dew point (75 to 250 SCFM models)
- Condition: New
- Weight: 99 lbs
- Ships from: San Juan, Texas
Technical support is available by phone from ProParts compressor technicians.
Part number cross-reference
100NCJ
Product Videos
Custom Field
Capacity SCFM 100 SCFM
In/Out Air Connect Size 3/4” NPT
Drain Connection 1/4” Nylon Tube
Max Operating Pressure 200 PSI
Refrigerant Compressor 1/2 HP
Operating 1.11 kW
Voltages 115V / 1ph, 60hz & 230V / 1ph, 60hz
Length 19.7 in
Width 15.2 in
Height 24.3 in
Weight 99 lbs
Timed Solenoid Drain Included
Pre & After Filters Included
Microprocessor Controller Included
