Product Description
The Mikropor MKUS-PRO-250-230-3-60 is an MK-US-PRO series refrigerated air dryer, model MKUS-PRO-250, configured for 230/3/60 AC power. It is listed in the non-cycling dryer category and is supplied new. ProParts, Inc. sells this dryer and ships it from San Juan, Texas, serving customers across Texas and Northern Mexico.
Details
- Brand: Mikropor
- Series: MK-US-PRO refrigerated air dryer
- Model: MKUS-PRO-250
- Electrical: AC 230/3/60
- Part number / SKU: MKUS-PRO-250-230-3-60
- Dryer type: Non-cycling
- Condition: New
- Ships from: San Juan, Texas
Technical support is available by phone from ProParts compressor technicians.
Part number cross-reference
MKUS-PRO-250-230-3-60; also referenced as MK-PRO-115-NPT-ZL-DPR0230360AC7012GONMKR.
Product Videos
Custom Field
Product Line Mikropor MK-US-PRO Refrigerated Air Dryer
Air Connection 2" NPT
Capacity (FAD) 250 scfm
Voltage 230V/1Ph/60Hz
Replacement Filter Kit MKON805 KIT
Pressure Drop 1.6 psig
Controller Digi-Pro
Dimensions (L x W x H) 26 x 27 x 50 in
Type Refrigerated Cycling Dryer (Digital ECO)
Max Working Pressure 232 psig
Min Working Pressure 58 psig
Max Inlet Temperature 140°F
Max Ambient Temperature 122°F
Refrigerant R-513a
Cooling Air-Cooled
