Product Description

Mikropor Air Quality Focus

Mikropor knows the importance of high-quality compressed air and provides customers with the highest quality air possible. Using clean, dry air is extremely important for most air powered applications. Moisture or contamination in the air from the compressor discharge will result in many complications to production equipment. These complications will decrease productivity and may affect the production quality of final product.

The Refrigerant Circuit and Insulation

Mikropor exclusively uses environmentally friendly R134a refrigerant gas in the dryers. This refrigerant is suitable for both low and high temperature applications. R-134a has excellent thermodynamic properties and can operate at very low pressure compared to other refrigerants. This will in turn increase the refrigerant compressor’s service life. With R-134a Mikropor dryers can operate at very high ambient temperatures. Mikropor engineers add extra capability to the heat exchangers with a superior no loss insulation system. This perfect insulation philosophy continues to the refrigeration circuit side also. Superior insulation and oversized condensers (for ultra-high ambient temperatures) enable the MCY Series
Dryers to offer continuous air quality.

Compact Design

MCY Series Air Dryers are highly reliable, efficient, have small space requirements and offer low cost ownership. Integration of pre / post filtration within the dryer cabinet saves labor time, installation cost and valued production space. The compact size also offers flexibility and economy during transportation.

MCY Advantage

• Best-in-class low package pressure drop saves energy consumption from the supplying air compressor.
• Thermal mass technology offers stable pressure dewpoint at varying loads.
• Mikropor state of the art “3 in 1” cast aluminium heat exchanger provides unmatched longevity & cooling.
• Glycol cooling components are all stainless steel.
• 150 F Max inlet temp design max air flow.

Mikropor Advanced “3 in 1” Heat Exchanger

Thermally Optimized Encapsulated Design
• Air to Air Exchanger
• Thermal Mass to Air Exchanger
• Multistage Moisture Separation
High Strength Aluminium Design
Large Surface Area for Heat Transfer
Robust Cylindrical Casing

Process Air Quality Protection

Pressure drop is a large concern in compressed air. In many applications high pressure drops will cause a decrease in the pressure at the point of use which results the machines or processes not operating correctly. Presence of dirt particles and oil in the compressed air system may result in filter blockage. It is important for the end users and service technicians to recognize if there is a problem in the system. The performance of the filters directly affects the pressure drops and system performance. Therefore, it is very important that the filter elements are changed at the filter service time. MCY Series Digital Controls feature an alarm / warning
indicating the appropriate time to change the filter elements. When the indication should occur, the element change will assist to avoid loss of performance and pressure drop.
