Product Description
The genuine ELGi EG30PMSM (part number S017706) is a new 40 HP, 125 PSI variable speed rotary screw air compressor from the ELGi EG Series 15 to 60 HP permanent magnet range. It uses a permanent magnet motor with VFD main motor control, a slow speed, heavy duty air end and a direct coupled drive. ProParts, Inc. is an authorized ELGi dealer, and our compressor technicians are available by phone for technical support.
Details
- Brand: ELGi
- Part number / SKU: S017706
- Condition: New
- Weight: 2,401 lbs
- Direct coupled drive group with flexible jaw coupling
- 3-stage air/oil separation, less than 1 PPM oil carryover
- 2-piece air cooled oil cooler and aftercooler for high ambient applications, twin cooling fans
- Microprocessor controller; UL/cUL compliant control panel with phase monitor
- Full acoustical enclosure with powder coated panels and hinged doors
- 2-stage inlet air filter with pre-filter mat; factory mounted moisture separator with automatic drain
- Stainless steel control line tubing and flanged rigid piping
- Factory filled with Airlube UT PAO/POE synthetic lubricant designed for 8,000-hour life
- 5-year package warranty (parts and labor), lifetime warranty on air end, 48 hour Uptime Assurance Plan
- Ships from San Juan, Texas
Part number cross-reference
ELGi EG30PMSM = S017706
Product Videos
Custom Field
Motor Power 40 HP
Sound Level 69 dBA
Air Delivery 30 - 170 CFM
Working Pressure 100 - 175 PSIG
Control Type Load/No Load
Motor Efficiency 94.1%
Outlet Connection 1 1/2 Inch NPT
Voltage 460V, 60Hz
Length 67 in
Width 44 in
Height 62 in
Weight 2401 lbs
