Product Description
• Best Warranty for Belt-Drive Compressors!
6 Year Air End Warranty, 5 Year Warranty on the Motor, Coolers, and Reservoir
• 48 hour “Uptime” assurance plan
• Compressor featuring High efficiency, heavy duty air end with eta-v profile rotors
• Encapsulated design with major components such as intake, compression, and separation systems integrated for compact design, leak free operation, and minimal pressure drop
• Premium Efficiency TEFC motor with Class F Insulation
• Air end and motor connected via simple belt drive arrangement
• High efficiency air filter with pre-filtration mat. Intake air taken from outside package
• Wye-Delta starter mounted in control panel
• Superb quality inlet valve assembly with load/unload control and timed shutdown
• 3 stage air/oil separation system with verified low oil carryover of less than 2 ppm
• Oversized air-cooled oil cooler and after cooler assembly designed for high ambient applications. Coolers mounted in separate compartment providing excellent access for cleaning. Pre-filtration mat is included to ensure coolers remain clean
• High capacity “spin on” 10-micron oil filter element
• Microprocessor controller with pressure transducer and temperature sensor
• UL/cUL control panel with premium electrical components and phase monitor
• Heavy duty full enclosure complete with powder coated panels and (3) service doors providing easy access to maintenance items and very low sound
• Full complement of safety features with shut down and fault codes for ease of troubleshooting
• Factory fill with “Airlube UT” premium PAO/POE synthetic lubricant designed for 8,000-hour life
• 10hp to 20hp compressor.
• Oil injected, air cooled
• Belt driven airend
• Encapsulated airend design
• Low 2ppm oil carryover
• NEMA Super E motor with Class F insulation
• Microprocessor Controlled
• Load / Unload Regulation
• 1 year "bumper-to-bumper" warranty
• 6 year airend warranty
• 5 year motor, cooler, separator warranty
• 3 year VFD warranty
• Fixed speed and variable speed
Sales, service and parts across the USA and Mexico. ProParts, Inc. is an authorized ELGi distributor based in San Juan, Texas. We ship nationwide across the USA and Mexico and service ELGi compressors throughout both countries, with 24/7 response in the Rio Grande Valley, South Texas and Northern Mexico. Call (956) 462-0947 or WhatsApp us for a configured quote, options and lead times.
