ELGi EN04 5 HP 125 PSI Air Compressor with 60 Gallon Tank Mount and Timer Drain P/N EN04-125-60T-A2

Product Description

The ELGi EN04 (P/N EN04-125-60T-A2) is a new 5 HP, 125 PSI belt-drive rotary screw air compressor mounted on a 60 gallon tank with a timer drain. It uses a heavy duty air end with eta-v profile rotors in an encapsulated design that integrates the intake, compression and separation systems for compact, leak-free operation with minimal pressure drop. ProParts, Inc. is an authorized ELGi dealer.

Details

• Brand: ELGi
• Part number: EN04-125-60T-A2
• Rating: 5 HP, 125 PSI
• Tank: 60 gallon tank mount with timer drain
• Premium Efficiency TEFC motor with Class F insulation, belt-driven air end
• Direct across-the-line starter; UL/cUL control panel with phase monitor
• Inlet valve with load/unload control and timed shutdown
• Microprocessor controller with pressure transducer and temperature sensor
• 3-stage air/oil separation with verified oil carryover below 2 ppm
• Oversized air-cooled oil cooler and aftercooler for high ambient applications, with pre-filtration mat
• Spin-on 10-micron oil filter element; air filter with pre-filtration mat
• Full powder-coated enclosure with (3) service doors
• Warranty: 6 year air end; 5 year motor, coolers and reservoir; 48 hour Uptime assurance plan
• Condition: New
• Weight: 352 lbs
• Ships from: San Juan, Texas

Part number cross-reference

EN04-125-60T-A2 (EN0412560TA2). Phone technical support is available from ProParts compressor technicians.
