Product Description
The Bobcat SA20T is a new 20 HP tank-mounted rotary screw air compressor that combines the compressor and a 120-gallon tank in one compact, ready-to-work package, with an optional dryer and prefilter. ProParts, Inc. is an authorized Bobcat Industrial Air distributor and ships from San Juan, Texas.
Details
- Part number: SA20T
- Brand: Bobcat
- Power: 20 HP, belt drive
- Tank: 120 gallon, tank-mounted
- Voltage: pre-wired tri-voltage for 208, 230 or 460 V three-phase power; wye-delta starter
- Pressure: 125 psi standard; 100, 150 and 175 psi available with a pressure-conversion kit
- Motor: IP55-rated TEFC IE3 motor with high-efficiency airend
- Components: IEC/UL-CUL compliant
- Networking: connect up to four units without an external main controller
- Warranty: 5-year bumper-to-bumper
- Condition: New
- Weight: 1,212 lbs
- Ships from: San Juan, Texas
Technical support is available by phone from ProParts compressor technicians.
Part number cross-reference
SA20T
Specifications are per ISO 1217 and are subject to change.
Product Videos
Custom Field
Motor Power 20 HP (15 kW)
Maximum Pressure 125 psig std (175 max w/ kit)
Capacity (FAD) 79 CFM
Voltage 208 / 230 / 460 V (tri-voltage), 3 Ph, 60 Hz
Cooling Air cooled
Regulation Fixed Speed
Receiver Tank 120 gal
Integrated Dryer No
